For Sale by Kevins Equipment Co. KEC
Surplus Record Dealer Since 1995
Layne Sailer
713-69...> Show Seller's Phone Number 713-694-1790 Let the seller know you found their listing on Surplus Record!
Description
Description
Cut Capacity: 1-1/2 (38mm) Genuine Cut
1-3/4 (45mm) Severance
1 (25 mm) Pierce Capacity
Output Current: 30-120 Amps, Adjustable
Input Power: 208-230/460 VAC, 3ph, 50/60Hz,
78/74/37 Amps
220/380-415 VAC, 3ph, 50/60Hz,
75/44/40 Amps
Duty Cycle: 60% @ 120A, 100% @ 100A
Dimensions: Length 35 (889mm)
Width 24.5 (622mm)
Height 45.4 (1153mm)
Weight: 275 lbs. (126 kg)
Ship Weight: 377 lbs. (171 kg)
Panel Controls: On/Off Switch, Run/Set/Latch Switch,
Output Current Potentiometer
Panel Indicators: AC Power, DC Output, Temperature,
Gas Pressure
Work Cable: 20 ft. (6.1m) (includes clamp)
Input Power Cable: Refer to Following Options
Plasma Gas: Air, Nitrogen, Argon/Hydrogen
Pressure: 65 psi (4.5 bar)
Flow: 45-85 scfh (21-40 lpm)
Secondary Gas: Air, Carbon Dioxide, Nitrogen
Pressure: 60 psi (4.1 bar)
Flow: 340 scfh (160 lpm)
Total Flow: 426 scfh (200 lpm) Max.
Gas Supply
Connections: Inert B on rear panel
(plasma and secondary shop
air filter/regulator with Y
hose provided)
Pilot: Electrode to Tip
Control: Hand Torch Switch, Hand Pendant,
or Interface Cable
Torch Configurations
Torch: PCH/M-120
Hand: 70 or 90 Head
25 ft. (7.6m) or 50 ft. (15.2m) Leads
Machine: 180 Head
25 ft. (7.6m) or 50 ft. (15.2m)
Shielded Leads
Warranty: Limited Warranty; 2 yr. Power Supply,
1 yr. Torch
Certifications: IP-23C (water test), CSA,
Cut Capacity: 1-1/2 (38mm) Genuine Cut
1-3/4 (45mm) Severance
1 (25 mm) Pierce Capacity
Output Current: 30-120 Amps, Adjustable
Input Power: 208-230/460 VAC, 3ph, 50/60Hz,
78/74/37 Amps
220/380-415 VAC, 3ph, 50/60Hz,
75/44/40 Amps
Duty Cycle: 60% @ 120A, 100% @ 100A
Dimensions: Length 35 (889mm)
Width 24.5 (622mm)
Height 45.4 (1153mm)
Weight: 275 lbs. (126 kg)
Ship Weight: 377 lbs. (171 kg)
Panel Controls: On/Off Switch, Run/Set/Latch Switch,
Output Current Potentiometer
Panel Indicators: AC Power, DC Output, Temperature,
Gas Pressure
Work Cable: 20 ft. (6.1m) (includes clamp)
Input Power Cable: Refer to Following Options
Plasma Gas: Air, Nitrogen, Argon/Hydrogen
Pressure: 65 psi (4.5 bar)
Flow: 45-85 scfh (21-40 lpm)
Secondary Gas: Air, Carbon Dioxide, Nitrogen
Pressure: 60 psi (4.1 bar)
Flow: 340 scfh (160 lpm)
Total Flow: 426 scfh (200 lpm) Max.
Gas Supply
Connections: Inert B on rear panel
(plasma and secondary shop
air filter/regulator with Y
hose provided)
Pilot: Electrode to Tip
Control: Hand Torch Switch, Hand Pendant,
or Interface Cable
Torch Configurations
Torch: PCH/M-120
Hand: 70 or 90 Head
25 ft. (7.6m) or 50 ft. (15.2m) Leads
Machine: 180 Head
25 ft. (7.6m) or 50 ft. (15.2m)
Shielded Leads
Warranty: Limited Warranty; 2 yr. Power Supply,
1 yr. Torch
Certifications: IP-23C (water test), CSA,
Get Your Price from Kevins Equipment Co. KEC!
Buyers Who Viewed This Listing Also Viewed …
Thermal Dynamics #Master-Pak-50, Plasma Cutting System, 1/2" Cut capacity, 24' Torch Lead, 90 deg. PCH/M-75 Torch, 1 & 3 Phase, 208-460 V
Category: Plasma Cutters/Punches
Seller: Norman Machine Tool Ltd
Location: Baltimore, MD
Mfr: Thermal Dynamics
Model: MASTER PAK 50
Thermal Dynamics ‘Master Pak 50’ Plasma Cutting System, Inventory # 3750, Model: Master Pak 50, S/N: M32B35A186401B, Made in USA, PCH/M-75 Torch: 90°, Cutting Capacity: 1/2″, Amperage: 1ph -33-15; 3ph 15-7, Input: 208v-460v, Phase: Single / Three, 70% Duty Cycle, Equipment Included:, Torch Lead ...more
Thermal Dynamics #Pak-Master-150XL, plasma machine w/hand held torch
