For Sale by N S Machine Corp.
Surplus Record Dealer Since 1997
David Bryan
515-99...> Show Seller's Phone Number 515-999-2999 Let the seller know you found their listing on Surplus Record!
Description
Details:
Features:
Specifications:
Manufacturer: Gisholt
Model Num er: 4L
Serial Number: 976-18
Stock Number: 13248
Features:
12-1/2″ diameter hole through spindle
24″ 4-jaw chuck with 9-1/2″ hole
Bar stock support (rear)
Threading
Specifications:
Swing over bedways - 31-3/8"
Swing over cross slide - 24-1/2"
Spindle nose to turret face - 104"
Spindle speeds (12) - 11-275 RPM
Spindle nose - A1-20
Spindle bore diameter - 12-1/2"
Cross slide feeds - (16) 0.0025 to 0.088 IPR
Longitudinal & turret feeds - (16) 0.005 to 0.176 IPR
Threading - (90) 2 to 40 TPI
Cross slide turret travel - 14-1/2"
Chuck size - 24" (4-jaw)
Flange holders - 6
Motor - 30 HP
Motor speed - 1760 RPM
Volts - 230 / 460
Phase - 3
Cycle - 60
Amps - 76 / 38
Approximate dimensions - 203" x 93" x 72" high
Approximate weight - 21,000 lbs.
Inquire Further with N S Machine Corp.!
