For Sale by Cleveland Machinery Sales Inc
Surplus Record Dealer Since 1984
Frank Petitt
216-74...> Show Seller's Phone Number 216-741-8900 Let the seller know you found their listing on Surplus Record!
Description
WORK TABLE: 13" X 58"
MAX. TABLE LOAD (CENTER): 1,800 LBS.
X-AXIS TRAVEL: 40"
Y-AXIS TRAVEL: 22"
Z-AXIS TRAVEL: 20"
QUILL TRAVEL 6"
SPINDLE NOSE TO TABLE: 3-3/8"" TO 25-3/8"
SPINDLE CENTER TO COLUMN: 23"
SPINDLE TAPER: NST#40
SPINDLE SPEED: (2 SPEED) 0 ~ 4,000 RPM
3-AXIS DRIVE MOTOR: DC SERVO. MOTOR
RAPID FEED: 160 IPM.
CUTTING FEED: 120 IPM.
SPINDLE MOTOR: 6 HP. 3PH/ 220 V
COOLANT PUMP MOTOR: 1/5 HP
FLOOR SPACE: 120" L-R X 68"F-B X 100"H
WEIGHT: 5,200 LBS.
MAX. TABLE LOAD (CENTER): 1,800 LBS.
X-AXIS TRAVEL: 40"
Y-AXIS TRAVEL: 22"
Z-AXIS TRAVEL: 20"
QUILL TRAVEL 6"
SPINDLE NOSE TO TABLE: 3-3/8"" TO 25-3/8"
SPINDLE CENTER TO COLUMN: 23"
SPINDLE TAPER: NST#40
SPINDLE SPEED: (2 SPEED) 0 ~ 4,000 RPM
3-AXIS DRIVE MOTOR: DC SERVO. MOTOR
RAPID FEED: 160 IPM.
CUTTING FEED: 120 IPM.
SPINDLE MOTOR: 6 HP. 3PH/ 220 V
COOLANT PUMP MOTOR: 1/5 HP
FLOOR SPACE: 120" L-R X 68"F-B X 100"H
WEIGHT: 5,200 LBS.
Get Your Price from Cleveland Machinery Sales Inc!
