Cleaver Brooks #CB-700-50, Steam Boiler, Gas/Oil, 150 psi, 575 V, 1991

Used Cleaver Brooks Steam Boiler 1,725 steam lbs/hr, 2,792,000 BTU/hr, Model CB-700-50, 50 HP, MAWP 150 PSI, Fuel Natural Gas/Oil, Boiler Weight 7,000 lbs, Built 1991
Cleaver Brooks 50 HP 150 PSI High Pressure Steam Boiler
Equipment Description
Manufacturer: Cleaver Brooks
Model: CB 700-50
Boiler Horsepower: 50 HP
Boiler Type: Steam Boiler
Fuel Type: Gas/Oil
Design Pressure or Maximum Allowable Working Pressure: 150 PSI
Heating Capacity: 2,792,000 BTU/hr
Steam Capacity: 1,725 steam Lbs/hr
Year Built: 1991
Serial No: L-88676
GPH Oil: N/A
Electrical Requirements
Main Power Supply
Voltage: 575V
Phase: 3 PH
Hertz: 60Hz
Ampacity: 4.6 AMP
Minimum Circuit Ampacity: 5.0 AMP
Maximum Rating of Circuit Protection: N/A
Blower Motor
Horsepower: N/A
Air Compressor Motor
Horsepower: N/A
Oil Heater: N/A
Control Circuit
Volts: 120V
Phase: 1 PH
Hertz: 60 HZ
Ampacity: 7 AMP
Oil Pump Motor
Volts: N/A
Phase: N/A
Hertz: N/A
Ampacity: N/A
Overall Dimensions
Length: 10.75 ft
Width: 6.8 ft
Height: 6.5 ft
Boiler Weight: 7,000 lbs
Location: Florida
