Brown & Sharpe #13, universal tool & cutter grinder, 8" swing, 24" centers, 7" x 0.5" x 1.5" wheel capacity, 1.5 HP

Brown & Sharpe #13 Tool & Cutter Grinder
#13 BROWN SHARPE UNIVERSAL TOOL CUTTER GRINDERS
S/N 523-13-1994
STANDARD CATALOG SPECIFICATIONS
CAPACITY
Swing over table................................... 8
Distance between centers........................... 24
Distance from center line of work to
center of wheel spindle -Maximum.................. 12 1/4
-Minimum.................. 2 1/4
Distance center of wheel spindle to
top of table -Maximum............................. 12 1/8
-Minimum............................. 3 3/4
SPEEDS
Wheel spindle speeds (3)................. 2455, 3545, 5730 RPM
Head stock work speeds (3)............... 120, 300, 530 RPM
WHEEL SPINDLE SLIDE
Vertical adjustment................................ 8 3/8
SPINDLE SLIDE UPRIGHT
Transverse movement................................ 10 1/2
WHEEL SIZE
Takes wheels............................. 7 x 1/2 x 1 1/2
HEAD STOCK
Base swivels either side of zero................... 100 Degrees
SWIVEL TABLE
Angular settings, either direction................. 90 Degrees
EQUIPMENT FEATURES
1 1/2 HP Main drive motor.
1/6 HP Head stock motor.
Electrical controls.
Lever tail stock.
Approximate weight: 2,500 lbs.
Specifications are deemed accurate, however, subject to verification or prior sale.
