Description
DETAILED SPECIFICATION
| Basic Dimensions | |
| Height of Centers | 12" |
| Swing Over Bed | 24" |
| Swing Over Cross Slide | 16" |
| Distance Between Centers | 40" |
| Bed Width | 13.78" |
| Spindle | |
| Spindle Nose | D1-8 |
| Spindle Bore | 3-3/8" |
| Spindle Taper | MT #7 |
| Range Of Spindle Speeds | Auto Shift High - Middle - Low |
| Z-Axis Travel | 31.5" |
| X-Axis Travel | 11.6" |
| Rapid Traverse | 180 IPM |
| Cutting Feed Rate | 120 IPM |
| Tool | |
| Maximum Cutting Tool Size | 1" |
| CNC Axis | 2 |
| Controller | Centroid |
| Ways | Mobil Vectra #2 |
| Coolant Tank Capacity | 3.5 Gallons |
| Coolant | Mobil 1 Gear |
| Pneumatic | Air Tool Oil |
| Power Requirements | 20 H.P., 3 Phase, 208V to 230V (Max) |
| Warranty | One Year Limited Warranty |
| Horsepower | 10 H.P. |
| Dimensions ( L x W x H) | |
| WEIGHT | 7,000 Lbs. |
Features
Coolant System
RS-232 Interface
Tool Box & Tools
Automatic Lube System
Halogen Work Light
12" 3 Jaw Chuck
Hardened & Ground With Turcite-B Coating Guide Way
Full Guarding
Leveling Bolts & Plate
Centroid T400I Control With 15" LCD
100% Laser Tested For Positioning Accuracy & Repeatability
Operation Manual
USB 2.0 Port
60 GB Solid State Hard Drive
Single Position Quick Change Tool Post
Shop Floor Programming/Conversational
Digitizing Package With Software
1 Day Of Training & Set-Up, On Site
C5 Double Nut Precision Ball Screws Hardened & Ground For High Accuracy & Long Lasting
FC30 Mechanite Casting Main Frame With Annealed & Stressed Relieved For Long Term Reliability
Massive One Piece Casting Construction For Maximum Cutting Performance
14" Wide Bed Ways Designed To Provide Maximum Rigidity & Stability
