For Sale by Machinery Resources Intl
Surplus Record Dealer Since 1996
Sales Dept.
818-51...> Show Seller's Phone Number 818-514-1254 Let the seller know you found their listing on Surplus Record!
Description
Description:
New in 2000
Specifications:
It is the buyers responsibility to confirm all details and we encourage an inspection of the machine(s) and accessories prior to purchase.
General Specifications:
Swing Over Bed: 15.75"
Centers: 50"
Swing Over Cross Slide: 9.65"
Swing In Gap: 23"
Gap Width From Face Plate: 6.5"
Spindle Bore: 2.1"
Spindle Nose: D1-6"
Taper in Nose Bush: # 4 MT
Spindle Speed: 2,500 RPM
Rapid Traverse Rate: 120 IPM
All Threads Metric Pitches (up to): 14mm Pitch
Imperial T.P.I. (up to): 2 T.P.I.
Module Pitches (up to): 3.5 MOD
Diametral Pitches (up to): 8 DP
Main Motor: 10 HP
Electrics: 415V / 3ph / 60 hz
Machine Dimensions: 120" x 63" x 64" 4,000 lbs
Chip Tray: 45" x 32" x 21" 175 lbs
Coolant Tank: 45" x 32" x 10" 30 lbs
Transformer: 22" x 16" x 26" 300 lbs
Get Your Price from Machinery Resources Intl!
