For Sale by Smith Machinery Co
Surplus Record Dealer Since 2001
Jim Smith
515-23...> Show Seller's Phone Number 515-233-6330 Let the seller know you found their listing on Surplus Record!
Description
Specifications
Equipped With
Equipped With
Equipped With
Equipped With
Machine Specifications:
Maximum Cutting Capacity
Round (0°, 45°,60°) 14.1”, 13”, 7.9”
Round (0°, 45°,60°) 14.1”, 13”, 7.9”
Square 14” x 14”
Rectangular (0°, 45°,60°) 13” x 20”, 13” x 13”,13” x 7.8”
Bundle Width: 7.1” - 12.9”
w/ optional top clamps Height: 7.1” - 9.4”
Remnant Piece 6” at 90°
Blade
Variable Speed 50 – 328 fpm
Variable Speed 50 – 328 fpm
Size 16’ 1” x 1.25” x .042”
Motor
Saw Blade 5 HP
Motor
Saw Blade 5 HP
Hydraulic 1 HP
Coolant 1/8 HP
Auto. Material Feed System
Job Storage Up to 100 jobs
Job Storage Up to 100 jobs
Single Index Stroke 19.9”
Multiple Stroke Indexing 0” to 999”
(Automatic kerf compensation)
Weight 4,684 LBS
Power 230V, 3 PH, 60 Hz
(460, 3 PH, 60 Hz Option)
Floor Space 101” x 123” x 86”
Floor Space 101” x 123” x 86”
Work Bed Height 31.4”
*Please note that machine design and specs can change without notice Max AMP Draw - 230V: 18.01 - 460V: 9.01
Machine Features:
Allows for straight cutting and miter cutting from 0 to 60 degrees
Hydraulic cylinder supports the saw head with ball joint
Gearbox designed to accept high lateral pressure (no thermal distortion)
Inverter blade drive system which allows infinitely variable blade speeds
5.7” HMI touchscreen
Adjustable flood coolant system
Motor driven, synchronized wire blade brush
Carbide blade guides and bearing provides additional blade support
Rigid cast-iron guide arms
Automatic hydraulic blade tensioning device
Cast-iron hydraulic vise
Save-A-Blade feature
Precision feed pressure and feed rate dual valve system for optimal cutting performance Computer controlled multiple indexing up to 999” max length
Included Accessories:
Blade “clip” device eases blade changing when necessary by holding the blade on the
band wheel during installation, making it very easy for one person to change the blade. Hydraulic powered chip auger
Full stroke vises
Double retracting vises
Built in work light
Additional flushing hose for cleaning
Bi-metal saw blade
Tool Box with tools, leveling pads, and an additional wire brush
Operation & parts manual
Optional Accessories:
Vise Pressure Regulator (AHA-10400KIT) $1,395.00
Hydraulic Top Clamps (Part# C510M-24000) $4,795.00
Heavy-duty Roller Table 5’ long (Part# RT-5-26PM) Capacity- 4200lbs $4,095.00
Heavy-duty Roller Table 10’ long (Part# RT-10-26PM) Capacity- 7700lb $5,595.00
Heavy-duty Roller Table 10’ long (Part# RT-10-26PM) Capacity- 7700lb $5,595.00
Micro Droplet Applicator $3,895.00
Buck Boost Transformer for incoming power of 208V or below $1,995.00
Voltage change to 460V 3PH $995.00
Voltage change to 460V 3PH $995.00
QR Code Reader (Part# EP-QRCODE-1) $3,995.00
Cosen Mist - 1 Gallon $115.00
Cosen Mist - 5 Gallon $595.00
