Description
General Info
- Stock #: Sharp-1340VS
- Brand: Sharp
- Model: 1340VS
- Approx. Shipping Weight: 1550 lbs / 703.06 Kg
- Approx. Shipping Dimensions: 6.19′ L x 1.68′ W x 3.81′ H / 1.88m x 0.51m x 1.16m
Specifications
- Swing Over Bed: 13 in. / 330.2 mm
- Swing Over Cross Slide: 7.6 in. / 195 mm
- Swing Over Gap: 19 in. / 490 mm
- Gap Width (In Front Of Face Plate): 9.43 in. / 240 mm
- Distance Between Centers: 40 in. / 1016 mm
- Spindle Speed: 40 – 2000 RPM
- No. of Spindle Speeds: Variable (high/low)
- Spindle Nose: D1-4 camlock
- Spindle Bore: 1.56 in. / 39.62 mm
- Threads (Inch/Metric): 2 – 56 tpi / 0.5 – 12 mm
- Longitudinal Feeds: 0.0016 – 0.046 in. / 0.0406 – 1.168 mm
- Cross Feeds: 0.0005 – 0.015 in. / 0.0127 – 0.381 mm
- Leadscrew Pitch, Diameter: 8 tpi, 0.87 in.
- Cross Slide Travel: 6.18 in. / 157 mm
- Compound Travel: 3.75 in. / 95 mm
- Compound Width: 4.5 in. / 114.3 mm
- Bed Length: 64 in. / 1625.6 mm
- Bed Width: 8.5 in. / 206 mm
- Quill Diameter: 1.56 in. / 39.62 mm
- Quill Travel: 4 in. / 101.6 mm
- Quill Center Taper: MT #3
- Spindle Motor: 3 HP / 2.23 KW
- Voltage: 220V/440V
- Phase: 3 Phase
- Power Consumption (220V): 3 KVA / 10 amps
- Power Consumption (440V): 3 KVA / 5 amps
