CAPACITY. 50 TON, STROKE OF RAM. 16", MAX DAYLIGHT OPENING. 42", SHUT HEIGHT. 28", MIN RAM FACE TO BED. 26", BED WORKING SURFACE. 36" F-B X 52-1/2" L-R, DISTANCE BETWEEN THE POSTS. 26" F-B X 42" L-R, RECTANGULAR CUT OUT IN BED. 15" F-B X 20" L-R, BED HAS 2 T-SLOTS IN CENTER. 4" OFF CENTER, DRILLED & TAPPED RAM ...more
Dake Guided Platen Trim Press, Model # 27-692, Serial # 169146, Capacity:, Down stroke 150 ton Up stroke 65, Working Surface:, 35" front to back x 90" left to right, Mold Surface:, 53' front to back x 90" left to right, Daylight Opening: 38", Stroke: 22", Ram Speeds:, Advance 470 IPM, Intermediate 260 IPM ...more
F TO B BETWEEN THE POSTS IS 28". L TO R OVERALL IS APPROX 120". NOMINAL BED SIZE IS 101" X 42". TWO CYLINDERS: 5" BORE, 3.5" ROD, RATED AT 2546 PSI AND APPROX 52" STROKE. MAX DAYLIGHT IS 66". FULLY GUIDED WITH 31" BUSHINGS ON 4" DIAMETER POSTS. OPERATOR HEIGHT IS APPROX ...more
